24 Ports C19 20A/Port Dumb Power Distribution Unit (PDU)
24 Ports C19 20A/Port Dumb Power Distribution Unit (PDU),12Pcs 40A 1P CHNT Breaker
CUSTOMIZED SERVICE IS AVAILABLE.
|
24 Ports C19 20A/Port Dumb Power Distribution Unit (PDU) |
|
|
Input voltage
|
120V 3phase(LLLG)to 208V single phase |
|
240V Single phase(LNG) to 240V single |
|
|
415v 3phase(LLLNG) to 240V single phase |
|
|
480V 3phase(LLLNG) to 277V single phase |
|
|
Input Terminal |
200A 5 wires or 4 wires |
|
Frequency |
50/60Hz |
|
Total Current |
Max 480A of breaker,Max 20A per outlet |
|
Rating Output Voltage |
208~300VAC |
|
Socket Standard |
C13 (can be changed as client request) |
|
Outlet Quantity |
24Pcs C13 (can be changed as client request) |
|
Breaker |
12Pcs 40A CHNT 1P breaker with UL or CE (optional) |
|
Wire Specification |
UL certification,with flame retardant function |
|
Shell Material |
Metal sheet |
|
Dimensions |
L x W x H=1820*120*90mm |
|
Net Weight |
16.6kg |
